Blue Illuminated Black Ring Arcade Buttons
Black Ring Illuminated Arcade Buttons
Black Ring Illuminated Arcade Button is 46mm in diameter, which is a bit bigger than normal Aracade Buttons. But with the illuminated head, it is perfect for special installations. The Button itself has a diameter of 37mm.
In each button, there is a LED incl. resistor. You need 12V to power this LED, which 5V it's not that bright. The LED can be controlled separately. Also in every button there is the Microswitch with the typical "click",
You need at least 31mm free space in your box to mount this button, the hole needs to be 24mm in Diameter. The button can just be screwed into the hole, very easy to mount.
Shine up your control panel with some Illuminated Arcade Buttons!
- Perfect for use in any JAMMA Arcade Machine or MAME / 60 in 1 Arcade Machine
- Looks great plain, fantastic when illuminated
- LED & lamp holder
- Brighter with 12V to power LED
- 24mm mounting hole
- 1 x Black Ring Illuminated Arcade Button
- 1 x Fixing Ring
- 1 x LED light
- 1 x Bulb holder
- 1 x Microswitch
These buttons require crimped wires for Microswitch Connection
1 wire for ground connection (CO) and 1 wire for signal connection (NO).
These buttons require 6.3 mm crimped wires for connecting to the terminals on the bulb holder if you plan on using LEDs (LEDs sold separately).
1 wire for the positive connection and 1 wire for the negative connection
Pre-crimped wires and daisy chain ground harness can be ordered.
